The sound quality of the CMIT 5 remains consistent even if the microphone is rotated on its axis, since its directional pattern is the same in both the vertical and horizontal planes.
Three pushbutton-activated filters allow the microphone to adapt to the recording situation:
High-frequency emphasis (+5 dB at 10 kHz) enhances speech intelligibility, and compensates for high-frequency loss caused by windscreens;
A steep low-cut filter (18 dB/oct. below 80 Hz) suppresses wind and boom noise;
A gentle low-frequency rolloff (6 dB/oct. below 300 Hz) compensates for proximity effect.
Pairs of LEDs next to each pushbutton indicate the status of the filters. Even in darkness the user can read the settings and see that the microphone is operational. The settings are retained when the microphone is switched off.
The capsule and amplifier of the CMIT 5 are built as a single unit, unlike microphones of the SCHOEPS Colette series.
TECHNICAL SPECIFICATIONS
Supercardioid / lobe-shaped
40 Hz - 20 kHz
-35 dB (V/Pa), 18 mV/Pa
Equivalent noise level (A-weighted)
13 dB
24 dB
Signal-to-noise ratio (A-weighted)
81 dB
Maximum sound pressure level (THD < 0.5 %)
131 dB-SPL (P48)
Maximum output voltage
1.3 V (2.5 dBV) with 1 kΩ load
High shelf filter
switchable, +5 dB at 10 kHz
Low cut filter
switchable, 80 Hz, 18 dB/oct.
Proximity filter
switchable, 300 Hz, 6 dB/oct.
Minimum recommended load impedance
1 kΩ
Output impedance
50 Ω
Maximum cable length
> 400 m
Yes
Powering standard / Valid range
P48 / >34 V
Current consumption
4.4 mA (P48)
Common mode rejection ratio (at 1 kHz)
> 65 dB
Output
XLR-3M, analog, 1 channel
Length
251 mm
Diameter
21 mm
Weight
95 g
blue
custom color:
anthracite gray, chromagreen
